The PALSTAT Tool location module is determined to evidence the movements of items, tools, jigs etc. , which are stocked in tool location. Further is a possibility to create the control instruction cards for individual items and evaluate the preventive controls and repairs.

The purpose of this program is to evaluate suppliers according to defined criteria with the possibility of creating a custom catalogue of evaluation steps. The module allows the printing of the protocol regarding a suppliers evaluation with the possibility of sending this protocol by e-mail to suppliers.

The purpose of the PALSTAT Outgoing inspection module is to monitor, register and evaluate output products, parameters and quality indicators on the basis of a prepared control plan using the PALSTAT Control plan module. The module allows verification of the compliance of products/services delivered to the customer with the possibility to print clearances and hand-over reports and their long-term archiving in electronic form.

The MSA Module is determined for the analysis and processing of the measurement process by methods according to requirements within the automotive industry and their long time archiving.

The system module designed for management, registration and evaluation of non-conformities from the viewpoint of kinds of faults and their causes, determination of corrective and preventive actions with assignment of responsibilities to individual workers and management of tasks in the control of improvement of the quality management system.

The module Audit is designed for the creation, recording and evaluation of individual system/process audits according to a catalogue of questions with a possibility of recording/managing and dealing with remedial measures. Norms implemented in Audit module: CSN EN ISO 19011 Directive for auditing a quality management system, VDA 6, 6.1, 6.2, 6.3, 6.4, 6.7, ISO 9001, IATF 16 949, ISO 14001, ISO 18001, ISO 22000, AQAP 2110. Catalogue of audit question for the audit system itself.

The PALSTAT Archives program will allow you to identify and manage records/documents, long-term storage in the archives according to the ISO standard requirements and Act on Archiving and Act on Accounting.

The PALSTAT Training program serves human resource management for the registration of workers and their education, training, skills and experience. Furthermore for the determination and description of workplaces necessary for determining employee requirements. SW provides management and documentation of schooling/training/medical examinations with the possibility of effectiveness evaluation and cost of the action.

The QSD system enables dynamic creation, comments, approval, management and versions of documents in the electronic form, their distribution and spreading through current computer networks. It has been designed mainly for management of the quality control system, but due to its possibilities it may also be used for management of other kinds of documentation, EMS, technical documentation, documentation according to ISO 45001 Safety at Work, documentation of the HACCP system for the food industry,etc.

The PALSTAT Processes module serves for the identification, management, monitoring of processes and workplaces, as well as for human resource management, identifying the necessary professional competence of employees.

FMEA is a method which if used can avoid or mitigate risks appearing during development or design of a product DFMEA, in the technology and during production itself PFMEA. The purpose lies in the specification of all possible failures with regard to the importance of the probability that they may be revealed, with the aim to optimise design and processes. The program is useful for applications in the field of design, technology, development of tools, assessment of critical spots in the EMS system, safety at work, etc. The program is in full compliance with standards CSN ISO 9001 and requirements of the automotive industry - IATF 16949 chap.4.4 / 8.3 methodology AIAG - FMEA and VDA 4.2.

The Tasks module allows the management, monitoring and archiving of events and tasks during process management in the quality field using Palstat CAQ modules.

The purpose of the PALSTAT Input control module is to monitor, register, control and release input products and materials, to evaluate parameters and quality indicators on the basis of a prepared control plan using the PALSTAT Control Plan module.

SPC module is intended for statistic process control enabling based on sample selections of process variability, cause revelation and scrap. With the assistance of SPC statistic regulation through measuring, comparison and machine capability can be done. SPC uses AIAG methodics, VDA 4 and norm ISO 22514-2.

System PalstatCAQ offers a complete metrology solution in whole chain from calibration laboratory, via business metrology, gauges workshop to end user of measures. The purpose of the module is to provide metrological services according to law nr. 505/90 Sb., norms required EN ISO/IEC 17025 and related standards ČSN ISO 10012:2003.

The Reporting module allows the export and visualization of data from the PALSTAT CAQ system including the possibility to incorporate data from other database systems. Outputs / Reports from this module are available in various views and formats.

The PALSTAT Tools module serves to identify tools and devices for key processes, provides sources for maintenance of tool/device upkeep and helps to create an effective system of planned preventive tool maintenance.

The PALSTAT Preventive Maintenance module serves to identify devices for key processes of maintenance, provides sources for both preventive maintenance and maintenance performed after defects in machines/devices and helps to create an effective system of Total Productive Maintenance - TPM.

The APQP module includes processes of planning, organisation, monitoring and management of all project activities in real time so that the required project objectives may be achieved. Processes and objectives of quality management apply to all project management processes used above all: to plan and implement projects introducing new products, to implement new technologies according to methodologies meeting requirements of standards to manage and implement procedures changing already functioning processes to improve the quality of processes and products in the case of changes in organisation and projects. The PALSTAT Project complies with the requirements of standards and the automotive industry ČSN ISO 10006 Quality Management Directive for quality in project management APQP Modern production planning/Advanced Product Quality Planning and Control Plan.

The module is designed for monitoring, evidence and evaluation of process and outgoing inspection of materials / products and moreover also for the evaluation of parameters and quality characters. The condition of the function is to complete the individual part and contact databases, creation and release of the control plan.

The module serves to control and assess non-conformities, both internal and those received from customers from the viewpoint of defects and causes, immediate corrective and preventive actions to be taken. The program fully complies with the requirements of standards ČSN ISO 9001 and IATF 16949 chap. 8.7 and uses the Ford Global 8D methodology to deal with non-conformities.

The PALSTAT Sampling Production Part Approval Process module serves to ensure quality before serial production according to the AIAG, PPAP/VDA 2 methodologies with a possibility to store and save the measured values and to print standard protocols. The PPAP/VDA 2 process defines type requirements for the approval of products including production and material volume.

Control and technical plans

The purpose of the integrated Control Plan/CTP module is the easy creation and maintenance of Work-flow of the Technical Control Process according to the requirements of IATF 16949, AIAG/APQP, VDA 4.3 and customer requirements. The created Work-flow can be used in the FMEA module. For its creation information from the Parts and Contacts module are used.

This module for the evaluation of product quality according to the VDA 6 part 5 Product Audit methodology serves to verify the product conformity after a check against defined quality requirements. The quality management must perform product audits in relevant production and delivery stages so that their conformity with all specified requirements, such as e.g. product sizes, functionality, packaging or marking, can be verified in the defined intervals.

Module to define and assign basic quality specifications and indicators (material, control dimensions, sizes) to individual parts, production groups identification by means of the parts unambiguous number and its change condition.

Documents

Management and archiving of electronics documents for quality management

- creation, change and electronics management and documents distribution for quality management
- quality manual, documentation of quality management, working instruction

Register, Identification, managment and distribution external "Print" documents - Technical plans, Drawings, Norms and customer specificatio

Metrology

Assurance of requirements in the area of metrology, control of inspection, measuring and testing proceedings according to requirements of the present law about Metrology and following norms

- ISO EN 9001, IATF 16949 chap. 7.1 and 9.1
- ČSN EN ISO 10012
- EN ISO/IEC 17025
- MSA IV. edition by AIAG
- VDA 5 2. edition

Maintenance

Planning, management and identification for key procesess, resouces provision for Machines and Tools maintenance and devices. Creation of effective management for preventive planning of maintenance.

Management of Tollcrib and devices designed to products manufacturing with possibility of state monitoring and quality state.

Audits

System audits by ČSN EN ISO 19 011 requirement, Process by methodics VDA 6.3 - internal audits including all sections and levels, and they are carry according to requirement of technical specification and other system requirement:

- ČSN EN ISO 9001

- IATF 16949

- VDA 6 part 1

Product audits according to VDA 6.5 methodics for evaluation of quality product and verification product compliance with established requirements for quality

Quality monitoring

An area for application of methods for monitoring and measurement of Quality management system processes. These monitoring methods show a capability to achieve planned results and furthermore they enable to monitor and measure features of verified product, whether product requirements have been met.

These required inspections and testing are performed in reasonable product making process stages in accordance with the Inspection plan, inspection operations generated within PALSTAT CTP Control Plan .

Evidence of consistency with acceptance criteria are recorded in an electronic form. Records also indicate people authorizing product release.

Faults

It is necessary to generate and administrate documented procedures so as it is ensured that product, which is not in conformity with specified requirements, will not be used or installed. This proceeding has to ensure identification, documentation, evaluation, separation (if it is suitable), handling of non-conforming product and reporting to functions, which are involved.

Modules serve for managing and evaluating internal and customer non-conformity/complaints with regard to defects and causes, establishing immediate, corrective, preventive measures and costs of non-conformity/complaints, analysis of faults and defects for preventing future causes of defects according to the Global 8 D method for the problem solving process with the option of G8D Report printing

Furthermore documented procedures for enforcing corrective and preventive actions have to be generated and administrated.

Events

Collection and management of tasks and measures, electronic management of contacts, electronic archiving of documentation and Reporting - extraction of information based on defined SQL Query

Quality planning

Quality planning is a structured method of definition and determination of actions necessary for assurance of meeting customer product or service requirements.

Area of quality processes planning is focused on quality management support in pre production stage thus within quality development planning stage and it demonstrates itself by attention to the whole process from product development initiation up to production initiation with an objective to achieve material and information flow, which is more effective and less costly. This necessarily shortens development work and delivery terms of new products/services.

The objective of product quality planning is to determine communication of implementation team involved in this process in such a way that ensures completion of all planned and defined activities in time.

Processes

Identification, managamement and monitoring of processess and working places, management of human recources, determining of necessary vocational qualification of employees

Management and training provision with evaluation their effectiveness and archiving of information about executed training and training costs

The module is designed for recording, identification, management and distribution of external "print" documents - technological procedures, drawings, standards and customer specifications.

This module is intended for registry of partners (suppliers, customers and other) including all important information about them (addresses, employees, phone,...). It is part of the basic package SW Palstat and it is used by other modules for contact specification.

The Job Orders module is intended for the identification of a production batch. These batches are assigned to In process or SPC modules. Very often job orders are generated from the ERP system. Basic linkage of a job order to a part in the Parts database module.

This module is designed for simplified, user friendly record entry about incurred faults in production and their transmission to modules G8D Report or Complaints. Is not separately salable. It is necessary to buy with module G8D Report or Complaints.

Module is designed for the documentation and graphical analysis of cause included for action assessment.

Driver PC-DMIS

Driver Mahr/Zeiss ULM

Driver for CAD dimensions import

Driver Boeco Balance

Driver Sony MG10

Driver Stotz

Driver Torrey series L-EQ

Driver Elcometer

Driver Impact

Driver InSpec

Driver Marposs

Driver Mahr MarWin

Driver Q-DAS/AQDEF

Driver Mitutoyo QVPAK

Driver Sprint MVP

Driver Werth

Driver Zeiss Calypso

Driver Sylvac OptoRS232

Driver Radwag

Module Laboratory is determined to data input and requirements administration for laboratory tests, managing work in corporate laboratories and archiving of laboratory tests results

Driver Ruska Series 7615

Driver Mahr RS232

Driver Trimos

CAQ Server is licensed module in PalstatCAQ system which allows access data and reports in other enviroment and forms. This module is designed to run on server and consists of several components (system service, scheduled tasks, web module and IIS service)

Driver MarCom

Opticon L-51X 1D/2D code reader

Opticon awards the user with a free worldwide accesible setup tool as an addition to the standard way of setting up the device using pa rinted barcode manual.

The L-51X is the successor of the L-50X and comes with an even more advanced 2D imager. With auto-focus and a speed of 100 fps the engine in the L-51X is truly next gen, but maybe the most important part is not the technology inside but the design on the outside, where the L-51X gives you the option to insert your own logo or design of your choosing.

The L-51X is often used in service settings; healthcare for wristband scanning, retail for scanning products and scanning e-tickets from mobile phones at festivals or other social gatherings. The usage often decides what type of engine should be inside the scanner. Because of the complementary stand, that activates the auto trigger, it is often used to scan without hands.

The L-51X is a pistol-grip designed cabled scanner with a very advanced 2D imager that scans at a speed of 100 fps. Furthermore, the design makes it possible to add your own design, image or logo to the top of the scanner, this way you can use the product to expand your brand visibility or presence. This addition is truly unique and as far as we are aware only Opticon offers this option.

Moreover, this handheld scanner comes with USB or RS232 and a complimentary stand for hands free scanning. The product is sealed with a rating of IP42 that can withstand drops from up to 1.5 meters upon concrete. The scanner gives visual and non-visual feedback when a scan action is performed, telling you if the scanning action succeeded or not.

Features:

Possibility to expand brand presence / visibility

1D & 2D scanning at a speed of 100 fps

Well thought out design for comfortable use

Comes with a stand for hands free scanning.

Technical Description

Functionality & Operation
Communication interface	USB
1D Barcode Symbologies	All standard one-dimension barcodes
2D Code Symbologies	all standard 2D-Codes
Optical
Scanning rate	100scan/s
Bar code scanner	2D Imager
Electrical
Power Source	+5 VDC ±5%
Mechanical
Dimensions	Width: 75.4mm, Height: 169.5mm, Length: 121.2mm
Weight	145g
Environment
Operating temperature	-20 to 50°C
Storage temperature	-30 to 60°C
Maximal ambient light	10000lux
Shock resistance	drop from 1,5 m onto concrete surface
Storage humidity (non-condensing)	5 to 90%
Operating humidity (non-condensing)	5 to 90%
Ingress protection	IP42
Vibrations resistance	10-100 Hz with 2G for 1h.
Others
Certifications	CE, FCC, VCCI, RoHS, IEC 62471 Extempt
Bundled Accessories	stand, power supply
